  • Position Sensor - Rotary Contactless - Hall Effect Technology


    © Vitesco Technologies

    • Small sensor size
    • Through aluminum wall measurement
    • High air-gap
    • Compatible with Ferrite Magnets
    • Compliant with ISO26262 (safety requirement)
    • Overall accuracy: ± 2%
    • Target: NdFeB, ferrite magnet
    • Measuring range: up to 360°
    • Air gap: up to 11 mm
    • Operating temp.: -40 up to 150°C according to application
    • Operating voltage: 5V ± 0.5V
    • Output signal: Analog, PWM, SPI or SENT

    Vehicle Types
