  • Pressure Sensor - Air Conditioning Pressure


    © Vitesco Technologies

    • Robust sensing technology compatible with typical exhaust environment
    • Flexible calibration of transfer functions
    • Precision programmable clip levels
    • Internal and output diagnostic capability
    • High accuracy and temperature stability
    • Fulfills toughest EMC requirements
    • Flexible housing, connector and mounting design
    • Flexible calibration of transfer functions
    • Pressure range: Typical 35 bar high side & 10 bar low side
    • Accuracy: 1% full scale and temp. range: -40°C up to 140°C
    • Supply voltage: 5V ± 0.5V and supply current at 5V: 10 mA max
    • Output: Analog

    Vehicle Types
